Can Modified Genes Escape from GM Crops
On the previous page of this chapter you read of a field experiment conducted in 2004 by the Environmental Protection Agency to assess the possibility that introduced genes could pass from genetically modified golf course grass to other plants. Investigators introduced a gene conferring herbicide resistance (the EPSP synthetase gene for resistance to glyphosate) into golf course bentgrass, A. stolonifera, and then looked to see if the gene passed from the GM grass to other plants of the same species, and also if it passed to other related species.
The map at the bottom displays the setup of this elaborate field study. A total of 178 A. stolonifera plants were placed outside the golf course, many of them downwind. An additional 69 bentgrass individuals were found to be already growing downwind, most of them the related species A. gigantea. Seeds were collected from each of these plants, and the DNA of resulting seedlings tested for the presence of the gene introduced into the GM golf course grass. In the graph, the upper red histogram (a histogram is a "bar graph" that sorts data into a series of discontinuous categories, the value of each bar representing the number of individuals in a category, or, as in this case, the average value of entries in that category) presents the relative frequency with which the gene was found in A. stolonifera plants located at various distances from the golf course. The lower blue histogram does the same for A. gigantea plants.



Interpreting Data
a. What general statement can be made about the effect of distance on the likelihood that the herbicide resistance gene will pass to another plant
b. Are there any significant differences in the gene flow to individuals of A. stolonifera and to individuals of the related species A. gigantea
