In an isometric drawing, the three principal planes and edges make equal angles with the plane of projection.

Name: In an isometric drawing, the three principal planes and edges make equal angles with the plane of projection.
Brand: Quizplus
Rating: 4.7 (31 reviews)

Question

Quizplus · Accepted Answer

In an isometric drawing, the three principal planes (frontal, horizontal, and profile) and edges are tilted at equal angles with respect to the plane of projection, resulting in a realistic three-dimensional representation.
